ADI-10xxx








    ADI-08200 ADI-10250 ADI-10350 ADI-12350 ADI-15350
Output Power (W) 8 10 10 12 15
Output Current (mA) 200 250 350 350 350
Output Voltage Range (V) 20-40 20-40 14-29 17-34 22-43

  • High power factor, low harmonic
  • Power Factor 0.98, Efficiency min.0.92
  • Protection with insulated transformer
  • Over temperature, overload and short-circuit protection
  • Compact housing for installation in tight spaces
  • 50,000 hours lifetime, 5 years warranty
  • Suitable for class I and class II luminaires
  • Complies with EN 61347-2-1, EN 61347-2-13, EAC and CE norms
KodPowerCurrentDimensionsNorm Voltage
ADI-082008W200mA 87/70x43x29mm20-40V
ADI-1025010W250mA 87/70x43x29mm20-40V
ADI-1035010W350mA 87/70x43x29mm14-29V
ADI-1235012W350mA 87/70x43x29mm17-34V
ADI-1535015W350mA 87/70x43x29mm22-43V
